Scope of certification 證書清表
|
Model機型 |
Voltage電壓（V) | Current電流（A) | Power功率（W)max |
| AK65WG-xxxyyyyW1 / AK65WG-xxxyyyyW2 | 9.0-24.0 | 0.01-6.0 | 72.0 |
| 24.1-36.0 | 0.1-3.0 | 72.36 |
·Safety & EMC&AC pin安全&輻射傳導&國家
√IEC62368-1(CB/II)、IEC62368-1(CB/I)
√UL62368-1（II)、UL62368-1(I)
√EN62368-1(II):CE/GS/UKCA
√EN62368-1(II):CE/GS/SAA
√EN62368-1(I):CE/GS/SAA/UKCA
√GB4943.1(II)、GB4943.1(I)
√EN6950-1(II):PSE/KC
√EN6950-1(I):KC
√Fcc part15 B/EN55032/EN55035/EN55024
√Cert:USA/Europe/Germany/UK/Australia/China/Japan/Korea
| FEATURE性能特點 | |
| Protection functions保護 | OCP/SCP/OVP/OTP |
| Efficiency level能效 | DOE-VI/CEC-VI/ERP-VI |
| Altitude海拔 | 5000M |
| Operational temperature工作溫度 | -10-45℃ |
| Surge雷擊 | 1KV/4KV(2pin)；1/2KV(3pin) |
| EFT瞬變電快速脈沖群 | 1KV |
| ESD靜電 | 8/4KV |
| Y-cap Y電容 | 1Y |
| CC or CV mode恒壓/恒流 |
恒壓/恒流 |
 |
 |
 |
 |
 |
 |
 |
 |
