Scope of certification 證書清表
|
Model機型 |
Voltage電壓（V) | Current電流（A) | Power功率（W)max |
| GJ48WE-xxxyyyyZ
GJ48WE-xxxyyyyW2 GJ48WE-xxxyyyyW1
|
5.0-6.5 | 0.01-6.0 | 30.0 |
| 6.6-9.0 | 0.01-4.5 | 40.5 | |
| 9.1-32.0 | 0.01-4.0 | 48.0 |
·Safety & EMC&AC pin安全&輻射傳導&國家
√ IEC62368-1(CB，II),IEC62368-1(CB，I)
√ UL62368-1(II),UL62368-1(I)
√ EN62368-1:CE/GS/UKCA/SAA/PSE
√ GB4943.1
√ Fcc part15 B/EN55032/EN55035/EN55024
√ Cert:USA/Europe/Germany/UK/Australia/China/Japan
| FEATURE性能特點 | |
| Protection functions保護 | OCP/SCP/OVP/OTP |
| Efficiency level能效 | DOE-VI/CEC-VI/ERP-VI |
| Altitude海拔 | 5000M |
| Operational temperature工作溫度 | -10-40℃ |
| Surge雷擊 | 1KV/4KV/6KV |
| EFT瞬變電快速脈沖群 | 1KV |
| ESD靜電 | 8/4KV |
| Y-cap Y電容 | 1Y |
| CC or CV mode恒壓/恒流 |
恒壓/恒流 |
 |
 |
 |
 |
 |
 |
 |
