Scope of certification 證書清表
|
Model機(jī)型 |
Voltage電壓（V) | Current電流（A) | Power功率（W)max |
| AK18WG-xxxyyyyZ | 5.0-7.5 |
0.01-3.0 |
15.0 |
| ? | 7.6-24.0 |
0.01-2.37 |
18.0 |
·Safety & EMC&AC pin安全&輻射傳導(dǎo)&國家
√IEC62368-1(CB)
√UL62368-1
√EN62368-1:CE/GS/UKCA/KC/SAA
√GB4943.1
√EN60950-1:PSE
√Fcc part15 B/EN55032/EN55035/EN55024
√Cert:USA/Europe/Germany/UK/Australia/Korea/Japan/China
| FEATURE性能特點 | |
| Protection functions保護(hù) | OCP/SCP/OVP/OTP |
| Efficiency level能效 | DOE-VI/CEC-VI/ERP-VI |
| Altitude海拔 | 5000M |
| Operational temperature工作溫度 | -10-40℃ |
| Surge雷擊 | 1KV/4KV/6KV |
| EFT瞬變電快速脈沖群 | 1KV |
| ESD靜電 | 8/4KV |
| Y-cap Y電容 | 1Y |
 |
 |
 |
 |
 |
 |
 |
 |
